The calibration service from B+B

A comprehensive calibration service addresses the issues of growing quality demands and increasingly stringent guidelines. These fundamentally lead to ever higher requirements, rules and specifications in production, manufacturing and storage processes. Accordingly, more and more processes are being monitored, tested and documented by measurement technology everywhere. Without exception, the various quality management systems require that all measuring and testing devices used are regularly and verifiably tested for their reliability and measuring accuracy.

The B+B calibration laboratory is accredited by the German Accreditation Body (DAkkS) according to DIN EN ISO/IEC 17025:2018 for the thermodynamic measurands temperature and relative humidity. In a calibration, the deviation of a measured value from the true, correct value of the measurand is specified. The result of the calibration is documented in a calibration certificate. Due to the fact that every measuring device ages and drifts on the basis of environmental influences or its use, further measures are applied. Regular calibrations show the behavior of the measuring device and increase the safety in its use.

Temperature

Resistance thermometers and thermocouples in particular can be distinguished at this point.

Humidity

Here hygrometers with rod probes, hygrometers with measuring point are calibrated on request.

Pressure

At this point, all pressure gauges are calibrated for negative, positive and absolute pressure.

Accredited calibration

The DAkkS accreditation ensures that all of our calibrations carried out in accordance with DIN EN ISO/IEC 17025:2018 can be traced back to national and international standards. This means that both the reference standards are calibrated in a traceable manner and that validated procedures are used. Thanks to an agreement with the ILAC, DAkkS calibration certificates are internationally recognized and legally binding. In addition to the DAkkS accreditation symbol, our calibration certificates also bear the ILAC mark.

Traceability is the seamless connection via a calibration hierarchy to national or international standards. The mandatory specification of a measurement uncertainty ensures reliable measurements by the user.

Many standards require accredited calibrations as proof of certification, and internal company quality requirements can also require the use it.

Advantages

  • National and international recognition of the calibration certificates
  • Reliable information on the stability of the measuring equipment through regular repeat calibrations
  • Consistent quality and reliability of your measurements in the process
  • Audit security
  • Production of the metrological feedback with indication of a measurement uncertainty, determined according to an internationally recognized method

Works calibration (ISO calibration)

A works calibration certificate documents the calibration position of the calibration item, the uncertainty of the standards used is specified in the calibration certificate. The standards used for this are subject to regular test equipment monitoring as part of our DAkkS accreditation and are usually the same as those for the accredited calibrations.

Whether a works calibration certificate is sufficient depends on the requirements of the quality management system used. The DIN EN ISO 9000ff series of standards requires that process measuring equipment be calibrated against traced reference standards. In this case, this is a cheap alternative to the accredited calibration.

An accredited calibration is much more complex than an ISO calibration because the uncertainty of the calibration item is taken into account to a much greater extent.

The determination of the measurement uncertainty is the biggest difference between a works calibration and a calibration according to DIN EN 17025. The latter produces the measurement feedback and is recognized nationally and internationally.

Advantages

  • Cost-effective calibration, sufficient fulfillment of audit requirements according to DIN EN 9000ff.
  • Fast turnaround and processing time
  • Quality assurance

That’s what we offer

We offer users who work with tolerance specifications in their measuring and testing equipment the possibility of adjusting our own products, which is primarily common for hygrometers and pressure transmitters. An adjustment is always performed after consultation with the customer, an input calibration certificate and an output calibration certificate are obligatory in case of an accredited calibration, in case of an ISO calibration according to the specifications of the customer’s quality management system.

In der Regel wird eine Justage empfohlen wenn die Messabweichung des Gerätes außerhalb seiner Spezifikation oder typischer vergleichbarer Messgeräte liegt.

Our characteristics

  • Competent personnel proven by our accreditation
  • High flexibility, practical orientation and customer proximity
  • Multiple availability of reference standards ensure uninterrupted operation
  • Reliability in traceability for the measurand temperature due to equipment with the water triple point and the gallium melting point
  • Adjustment of measuring instruments from our own production
  • Use of technical equipment from well-known manufacturers
